EnvisionTEC | E-Partial

The EnvisionTEC E-Partial resin also known as EC 1000 is designed to help the dental industry develop frameworks with thin features and some flexibility for casting.

$569.00
$512.10 Save 10%

($512.10 per kilo)

Tax excluded
Quantity

Compare now

The EnvisionTEC E-Partial Resin

E-Partial is a flexible and thin castable material formulated for very specific needs in the dental industry. It is the solution for the print of delicate appliances requiring flexibility such as retention grids and clasps. Just enough smooth to ensure flex but to prevent breakage, this material can be printed at a resolution of 25 microns for an excellent accuracy. Create tight and thin appliances fitting perfectly to your patients, with the EnvisionTEC material E-Partial.

Applications: Dental

Material Properties
DescriptionValue
Tensile Strength 57 MPa
Elongation at Break 3.6%
Flexural Strength 129 MPa
Flexural Modulus 3155 MPa
Heat Deflection Temerature 130° C at 9455 MPa, 78° C at 1.82 MPa
Shore D Hardness 89
Specific Gravity 1.1 - 1.11 g/cm3
Viscosity 760 cP at 25° C
EnvisionTEC

Data sheet

Heat Deflection Temperature
130° C at 9455 MPa, 78° C at 1.82 MPa
Tensile Strength
57 MPa
Flexural Strength
129 MPa
Flexural Modulus
3155 MPa
Shore D hardness
89
