EnvisionTEC | PIC 100 Series

The PIC 100 Series is a very versatile resin from the EnvisionTEC repertoire. The material can be used in the production of castables for various industries.

$370.00

($370.00 per kilo)

Tax excluded
Quantity

Compare now

The EnvisionTEC PIC 100 Series

The PIC 100 Series was designed for direct investment casting applications. The material builds with the highest quality and crisp detail. Additionally, this resin offers great burnout properties. Parts printed with the PIC 100 Series are especially suitable for producing precious metal castings, they evaporate at moderate burnout temperatures without reacting with investment and offer very low thermal expansions. The surfaces produced are extremely smooth. The burnout process is ash free, allowing for a casting which is free from porosity. This resin is highly qualified for producing high quality castables in the jewellery market.

Applications:Entertainment, Jewellery, Consumer Goods, Education, Manufacturing

Material Properties
ASTMS MethodDescriptionValue
DIN EN ISO 527-1 Tensile Strength 16.8 MPa
DIN EN ISO 527-1 Elongation at Break 4.39%
DIN EN ISO 868 Hardness Shore D 69
DIN EN ISO 180 Izod Impact - Notched 11.03 kJ/m2
DIN EN ISO 178 Flexural Strength 23 MPa
DIN EN ISO 178 Flexural Modulus 404 MPa
DIN EN ISO 178 Bending Strain 10.2%
DIN 53765 Ignition Temperature 350° C
DIN ISO 1183-1 Density 1.178 g/cm3
DIN 1342-2 Viscosity 361.7 MPa
EnvisionTEC

Data sheet

Tensile Strength
16.8MPa
Viscosity
361.7 MPa
Elongation at Break (%)
7.46%

Specific References
