LOCTITE 3D | 3820 High Impact

The LOCTITE 3D 3820 Ultra Clear is a sturdy material for functional prototyping. The resin is clear and will not yellow over time.

$199.00

($165.00 Per Litre)

Tax excluded
Quantity

Compare now

Henkel Loctite Logo

The LOCTITE 3D 3820 High Impact Resin

The 3820 High Impact is a clear, non brittle resin developed for the use in functional prototyping. This material does not require the same time consuming post processing routine as other resins to showcase transparent properties.

Key Features

  • Clear finish
  • High impact material
  • Limited post processing required
  • Stable, non brittle
Mechanical PropertiesMethodGreenPost Processed
Elongation at Break ASTM D638 4 to 49 % 26 to 46 %
Tensile Strength ASTM D638 17 to 19 MPa 18 to 28 MPa
Tensile Modulus ASTM D638 370 to 450 MPa 520 to 840 MPa
Notched IZOD Impact ASTM D256 33 to 40 J/m 31 to 37 J/m
Volume Shrinkage 7.5 %
Linear Shrinkage ASTM D792 2.6 %
Shore Hardness (D scale) ASTM D2240 60

Specific References
