Artec Space Spider
Capture fine details with high accuracy and precision with Artec Space Spider 3D scanner. Unrivalled in it's scanning quality, it is proven to scan quickly and efficiently, while maintaining incredibly high resolution.
Free Shipping on orders over £75
Free lifetime remote support on all products
Why the Artec Space Spider ?
Use the Artec Space Spider to scan small areas, capturing intricate detail with great precision
CGI: Digitally capture a person or object to create a 3D CG model for use in visual effects
Utilise professional level Software for 3D scanning and processing
Enjoy fantastic adaptability and overcome the most challenging environments
Capturing 1 million data points a second the Artec Space Spider is capable of scanning small objects with high detail quickly.
Scan points up to 100 microns apart with an accuracy of up to 50 microns to capture intricate details and fine features.
With only two cables and weighing only 850g, the Space Spider is lightweight and can be moved around freely. The optional battery pack offers full portability.
Due to it's small size and compact design, the Space Spider can be used for all different kinds of objects, specialising in those on the smaller side.
"Down from 20 hours to just 1 Hour".
- 0.85 kg
- Scan size
- 90 x 70 mm (Closest)180 x 140 mm (Furthest)
- Scanning Technology
- Structured light
- Scanning time
- 7.5 frames per second, 1 million points per second
- Light Source
- Blue LED
- 190 x 140 x 130 mm
- File Output Format
- OBJ, PLY, WRL, STL, AOP, ASCII, Disney PTEX, E57, XYZRGB
- Scan Resolution
- Up to 100 microns
- Scan Accuracy
- Up to 50 microns
- Scanning Software
- Artec Studio
- Power Supply
- 12v, 24w
- Working Distance
- 0.2 - 0.3 m
- Texture Resolution
- 1.3 mp
- Warm up Time
- 3 mins
- Software Compatibility
- Windows 7, 8 or 10 - x64, i5 or i7, min 18gb ram, graphics card
