• Asiga MAX X

    Asiga MAX X

    The MAX X is Asiga’s highest resolution jewellery production system, with a re-configurable resolution of 27, 35 or 43 microns the MAX X offers flexible precision for digital dentistry, jewellery, audiology and microfluidic applications.

    Includes FREE SHIPPING and a 1-litre bottle of Asiga resin of your choice.

    Tax included
    Choose Your Option
    Available to order. Dispatch within 3-4 weeks.


    Free Shipping on orders over £75


    Free lifetime remote support on all products

    Built on the precision of Asiga’s Smart Positioning System (SPS) Technology, the MAX X delivers performance, reliability and flexibility for jewellers and casting houses. The choice of 27, 35 and 43 micron configurations allows the system to be optimised for either high resolution or high productivity applications.

    Further optimisation is possible with the additional option of a UV (385nm) LED set-up - allowing the use of transparent materials - and 365nm for microfluidic applications.

    Build Volume (x,y,z)51.8 x 29.2 x 75mm67.2 x 37.8 x 75mm82.3 x 46.4 x 75mm
    Resolution27 microns35 microns43 microns

    View more details about the features included in all printers in the Asiga MAX Series

    For further information and advice on how Asiga MAX X printers can benefit your business, please do not hesitate to get in touch with one of our advisors by calling the telephone number at the top of the page, or by clicking the button below and requesting a call-back:

    Request a callback

    Data sheet

    Printing Technology
    Build Volume W x D x H (mm) // W x D x H (inch)
    X27: 51.8x29.2x75mm (2.04hx1.15x2.95 inches) // X35: 67.2x37.8x75mm (2.65x1.49x2.95 inches) // X43: 82.3x46.4x75mm (3.24x1.83x2.95 inches)
    Layer Thickness / Print Precision
    1 micron
    21.5 kg (47.4 lb)
    Material type
    Open - Asiga materials and suitable third party materials
    XY Resolution
    X27: 27 microns X35: 35 microns X43: 43 microns
    260x400x510mm (10.2x15.7x20 inches)
    Wifi, Ethernet
    Printer Software
    Asiga Composer
    Software Compatibility
    Windows, MacOS and Linux
    Input Voltage / Power
    Shipping Dimensions
    400x510x630mm (15.7x20x24.8 inches)
    Shipping Weight
    23.5 kg (51.8 lb)
