EnvisionTEC | E-RigidForm

    The EnvisionTEC E-RigidForm produces hard, stiff parts, so it is mostly used to print for prototypes and end use.

    £249.17
    Tax included
    Choose your package
    Quantity
    Available to order.



    Free Shipping on orders over £75



    Free lifetime remote support on all products

    EnvisionTEC E-RigidForm

    The E-RigidForm is a polyurethane-like resin that 3D prints strong, hard and stiff parts for prototypes and end-use. The high tensile strength compares to that of nylon 6 and polycarbonate. The resin has good heat deflection and water resistance and it is a versatile and though material. It has a hardness value of Shore D 87, which is the same value as a cast urethane plastic. This resin is ideal for a wide range of industrial and consumer applications.

    Applications: Aerospace, Automotive, Consumer Goods, Education, Manufacturing

    Material Properties
    DescriptionValue
    Tensile Strength68 - 73 MPa
    Tensile Modulus2950 - 3250 MPa
    Elongation at Break6 - 7%
    Flexural Strength120 - 126 MPa
    Flexural Modulus3340 - 3570 MPa
    Viscosity460 cP at 30° C
    Hardness Shore D87
    Heat Deflection Temperature62.5° C
    Impact Izod30 J/m
    Water Absorption0.67% at 48 hours
    Post-Processing For Results AboveUV SCU 2 X 60 min
    EnvisionTEC

    Data sheet

    Tensile Strength
    68 - 73 MPa
    Tensile Modulus
    2950 - 3250 MPa
    Flexural Strength
    120 - 126 MPa
    Flexural Modulus
    3340 - 3570 MPa
    Shore Hardness
    87
