LOCTITE 3D | 3843 HDT60 | High Toughness

The LOCTITE 3D 3843 HDT60 resin is a high toughness resin created with the user in mind. This is an engineering plastic used in the production of tools.

£154.17
Tax included
Colors
  • Black
  • White
  • Grey
  • Clear
Size
Quantity
In stock. Dispatch within 24 hours.

Compare now


Free Shipping on orders over £75



Free lifetime remote support on all products

Henkel Loctite Logo

The LOCTITE 3843 Resin

This high toughness LOCTITE resin is created for the use of tool manufacturing on the production line. The LOCTITE 3843 High Toughness has similar qualities as the ABS resins. Usage for this material is commonly tooling, low temperature molding, anatomical models and consumer applications, for example insoles.

Key Features

  • Tough resin with great surface finish
  • High heat deflection temperature
  • Sturdy material with high impact resistance
  • Superior strength
Mechanical PropertiesMethodGreenComplete
Tensile Stress at Yield ASTM D638 43 ± 0.57 MPa 45 ± 1.5 MPa
Tensile Stress at Break ASTM D638 38 ± 1.7 MPa 44 ± 2.7 MPa
Young's Modulus ASTM D638 1562 ± 36 MPa 1752 ± MPa
Elongation at Failure ASTM D638 58 ± 24 % 41 ± 6.7 %
Flexural Stress at Yield ASTM D790 79 ± 2.6 MPa
Flexural Modulus ASTM D790 1878 ± 81 MPa
Flexural Strain at Break ASTM D790 > 10 %
Other PropertiesMethodGreenComplete
Heat Deflection Temperature ASTM D648 63° C/td>
IZOD Impact Strength ASTM D256 65 ± 2.9 J/m
Shore Hardness (D scale) ASTM D2240 68D, 63D
Water Absorption ASTM D570 2.13 %
Solid Density (Green) ASTM D1475 1.173
Solid Density ASTM D1475 1.181
Viscosity at 25° C ASTM D7867 530 ± 150 cP
Liquid Density ASTM D1475 1.0682

Data sheet

Heat Deflection Temperature
63° C (at 0,455 MPa)
Tensile Strength
51 MPa (break)
Shore Hardness
75 (D)
Tensile Elongation
43 %
Young’s Modulus (MPa)
1800
Notched Izod Impact
53 J/m

Download

Loctite 3D 3843 data sheet

Download (1.25M)
